YMC4-1K Photovoltaic Connector PPO 30A 1000V Cable

Product features: Simple on-site processing Mating safety provided by keyed housings Multiple plugging and unplugging cycles High Voltage and Current carrying capacity Waterproof grade: IP67 Housing made of PPO material, anti-UV CE approved Competitive price Technical data: Name: Solar connector Rated current: 30A,45A Rated voltage: 1000v DC Test voltage: 6000V(50Hz, 1min) Overvoltage type/pollution degree: CAT Ⅲ /2 Contact resistance of plug connector: 1mΩ Contact material: Copper, Tin-plated Insulation material: PPO Degree of protection: IP67 Safety class: Ⅱ Suitable cable: 2.5mm2, 4mm2, 6mm2 Insertion force/withdrawal force: ≤50N/≥50N Connecting system: Crimp connection Operating Temperature: -40℃--+85℃
